Raincoat, pattern №1110

Sizes:

size 38, height 152-158
size 38, height 158-164
size 38, height 164-170
size 40, height 152-158
size 40, height 158-164
size 40, height 164-170
size 40, height 170-176
size 40, height 176-182
size 42, height 152-158
size 42, height 158-164
size 42, height 164-170
size 42, height 170-176
size 42, height 176-182
size 44, height 152-158
size 44, height 158-164
size 44, height 164-170
size 44, height 170-176
size 44, height 176-182
size 46, height 152-158
size 46, height 158-164
size 46, height 164-170
size 46, height 170-176
size 46, height 176-182
size 48, height 152-158
size 48, height 158-164
size 48, height 164-170
size 48, height 170-176
size 48, height 176-182
size 50, height 152-158
size 50, height 158-164
size 50, height 164-170
size 50, height 170-176
size 50, height 176-182
size 52, height 152-158
size 52, height 158-164
size 52, height 164-170
size 52, height 170-176
size 52, height 176-182
size 54, height 152-158
size 54, height 158-164
size 54, height 164-170
size 54, height 170-176
size 54, height 176-182
size 56, height 152-158
size 56, height 158-164
size 56, height 164-170
size 56, height 170-176
size 56, height 176-182
size 58, height 152-158
size 58, height 158-164
size 58, height 164-170
size 58, height 170-176
size 58, height 176-182
-

Size:

Height:

152-158
158-164
164-170
170-176
176-182

$11

After payment, links for downloads of patterns are sent to your e-mail. For registered users download links are also available in personal account in the section "My Orders".

Info

Comments

Questions

Raincoat pattern. Loose fit, A-line lined raincoat. The garment’s length is below the knee. The garment’s centre front closure has 5 buttonholes and 5 buttons. The front is designed with bust darts from the armholes, jetted pockets and storm flaps. The pocket openings are tilted and finished with welts with topstitched ends. The back is designed with a centre seam and a storm flap. The centre seam ends with a kick pleat which starts from the waistline. The pleat is sewn with a wedge-like section of fabric and it is fastened with a strap with a buttonhole and a button. The shoulder is lowered by 10.3-11.5 cm (depending on the garment’s size). The sleeve is set-in, full-length with lower seam and elbow seam, as well as with an attached bottom part. A strap is attached to the bottom part. The strap is fastened with one buttonhole and 2 buttons to adjust the volume of the sleeve hem. The neckline is round and it is finished with a roll collar with an attached collar stand. The garment features a detachable hood. The hood is of small volume and it is drafted with a centre piece. The front edge of the hood has a drawstring casing to adjust the fit of the hood with a cord. The ends of the drawstring cord are pulled to the right side through eyelets. The hood is fastened to the garment through the buttonholes, sewn along its lower edge, and buttons sewn along the right side of the neckline edge of the garment.

Eases added to a pattern, cm:

Size / The amount of ease	38	40	42	44	46	48	50	52	54	56	58
Bust-line	44,5-44,7	44,6-45,2	44,7-45,3	44,8-45,4	44,9-45,5	45,0-45,6	45,1-45,7	45,2-45,8	45,3-45,9	45,4-46,0	45,5-46,1
Hips-line	51,2-52,6	55,5-54,5	51,8-54,8	52,1-55,1	52,4-55,4	52,7-55,7	53,0-56,0	53,3-56,3	53,6-56,6	53,9-56,9	54,2-57,2

Shoulders: 19,0 cm (for all sizes in the height 152-158); 19,5 cm (for all sizes in the height 158-164); 20,0 cm (for all sizes in the height 164-170); 20,5 cm (for all sizes in the height 170-176); 21,0 cm (for all sizes in the height 176-182).

Garment Length Measurements, cm:

Size	38	40	42	44	46	48	50	52	54	56	58
Finished back length along the center back seam	99,8-107,0	99,9-114,3	100,0-114,4	100,1-114,5	100,2-114,6	100,3-114,7	100,4-114,8	100,5-114,9	100,6-115,0	100,7-115,1	100,8-115,2
Finished sleeve length	49,0-52,8	49,1-56,8	49,3-56,9	49,5-57,1	49,6-57,3	49,8-57,4	50,0-57,6	50,1-57,7	50,3-57,9	50,3-57,9	50,3-57,9

Fabric suggestion:

Main fabric. We recommend this garment mid-weight fabrics for raincoats or jackets: membrane outdoor fabrics, outdoor fabrics with or without waterproof coating. The fabrics can be natural, synthetic and blended.

Lining material. For lining we recommend using synthetic lining fabrics for membrane fabrics and natural, synthetic and blended lining fabrics for other outdoor fabrics.

Interfacing materials. For better quality of sewing, we recommend to use the interfacing material. For example, you may use 33 g/m2 density 150 cm, width woven interfacing. The density of the interfacing material depends on the main fabric density.

Amount of Fabrics (in metres):

Size	38	40	42	44	46	48	50	52	54	56	58
Main fabric, wide 140 cm	3,20-3,35	3,30-3,65	3,35-3,75	3,40-3,80	3,50-3,85	3,55-4,00	3,65-4,05	3,70-4,15	3,80-4,20	3,85-4,30	3,95-4,35
Lining fabric, wide 140 cm	1,85-2,10	1,90-2,35	2,10-2,35	2,10-2,40			2,15-2,45			2,20-2,50	2,25-2,55
Interfacing (density 33 g/m2; width 150 cm)	1,10-1,15	1,10-1,25					1,25-1,30
Fusible on grain tape	2,20-2,35	2,20-2,50		2,25-2,50		2,25-2,55		2,30-2,55		2,30-2,60
A hat cord, width 2 mm	0,25

Attention! Given exact fabric consumption can be used only when pattern details are placed on a fabric sheet close to each other. All pattern details should be arranged on an opened fabric sheet strictly on grain in one direction, each pattern piece must be cut out only once.

Accessories:

1.      Buttons 22-24 mm - 9 pcs.
2.      Buttons (backer buttons) 12-14 mm - 5 pcs.
3.      Button 16-18 mm - 1.
4.      Buttons 10-11 mm - 10pcs.
5.      Snap fasteners 12.5-15 mm - 2 pcs.
6.      Eyelets 9 mm with washers - 2 pcs.

Pattern is given with seam allowances.

Detailed sewing instruction with step-by-step photos of sewing is attached to the pattern in the kit.

Degree of difficulty - «Advanced».

The photos shows a raincoat sewed at the GRASSER for pattern №1110.

Model is wearing a size 42, height 170-176. Model parameters: Bust-line: 81 cm, Waist-line: 61 cm, Hips: 92 cm, Height: 174 cm.

The photo also shows: dress on pattern №1076, dress on pattern №1166.

For sewing you will need the following equipment:

1. Multipurpose sewing machine;
2. An iron with or without steam;
3. Regular presser foot;
4. Hinged cording foot;
5. Wooden iron;
6. Ironing desk or console table;
7. Hand needle for basting;
8. Machine needles №85-95 for the main fabric;
9. Machine needles №70 for the lining;
10. Paper scissors;
11. Scissors for textile cutting;
12. Snaps pressing machine to install accessories grommets and press studs, depending on the diameter.

The pattern in your order will be in two print options:

1. For printing on A4/Letter. You need to print the pattern on a regular printer on A4/Letter sheets, then glue the sheets, cut the pattern and you can sew!

A test square for checking the A4/Letter print scale is located on the first sheet of the pattern file.

2. For printing on a large format plotter.

A test square for checking the plotter scale is located on the pattern sheet.
