Coat and jacket, pattern №1001
Sizes:
-
size 38, height 152-158
-
size 38, height 158-164
-
size 38, height 164-170
-
size 40, height 152-158
-
size 40, height 158-164
-
size 40, height 164-170
-
size 40, height 170-176
-
size 40, height 176-182
-
size 42, height 152-158
-
size 42, height 158-164
-
size 42, height 164-170
-
size 42, height 170-176
-
size 42, height 176-182
-
size 44, height 152-158
-
size 44, height 158-164
-
size 44, height 164-170
-
size 44, height 170-176
-
size 44, height 176-182
-
size 46, height 152-158
-
size 46, height 158-164
-
size 46, height 164-170
-
size 46, height 170-176
-
size 46, height 176-182
-
size 48, height 152-158
-
size 48, height 158-164
-
size 48, height 164-170
-
size 48, height 170-176
-
size 48, height 176-182
-
size 50, height 152-158
-
size 50, height 158-164
-
size 50, height 164-170
-
size 50, height 170-176
-
size 50, height 176-182
-
size 52, height 152-158
-
size 52, height 158-164
-
size 52, height 164-170
-
size 52, height 170-176
-
size 52, height 176-182
-
size 54, height 152-158
-
size 54, height 158-164
-
size 54, height 164-170
-
size 54, height 170-176
-
size 54, height 176-182
-
size 56, height 152-158
-
size 56, height 158-164
-
size 56, height 164-170
-
size 56, height 170-176
-
size 56, height 176-182
-
-
Size:
- 38
- 40
- 42
- 44
- 46
- 48
- 50
- 52
- 54
- 56
Height:
- 152-158
- 158-164
- 164-170
- 170-176
- 176-182
After payment, links for downloads of patterns are sent to your e-mail. For registered users download links are also available in personal account in the section "My Orders".
Info
Comments
Questions
Coat and jacket pattern. It’s a straight silhouette insulated lined knee length (option 1) coat.
It’s a straight silhouette insulated lined hip length (option 2) jacket.
Center front zipper closure features an underlap placket. Front comes with set-in zipper pockets with decorative seams on their lining details. Front’s upper part features a diagonal pocket. Bottom part of front features a horizontal pocket. Back comes with a yoke and center seam. There are drawstring casings at the waistline and at the hemline, each features a cord to adjust the fitment. Ends of the cords are outside of the garment, they are inserted into grommets. Shoulder seam is lowered for 8,5 cm.
Set-in shirt type sleeve has two seams. Underarm seam of a sleeve comes with a pleat. Hem edge of a sleeve is finished with a 10 cm width cuff. Slit of a sleeve is finished with an insert detail. Cuff comes with a snap button closure. Roundish neckline is finished with a turn-down collar and a collar stand. The garment features a detachable hood. Hood’s volume is small and it features a center part. There is a drawstring casing with cord in the facial edge of the hood, cord’s ends are outside of the garment, inserted into grommets.
Hood is attached to the garment by loops and buttons on the neckline of the garment’s inner side.
Eases added to a pattern, cm:
CONSTRUCTIVE EASE (EC)*:
Bust-line – 32,4 cm.
Hips-line – 30,0 cm.
Shoulders – 22,7 cm (for all sizes in the height 152-158)
23,4 cm (for all sizes in the height 158-164)
23,9 cm (for all sizes in the height 164-170)
24,7 cm (for all sizes in the height 170-176)
25,4 cm (for all sizes in the height 176-182)
Constructive ease consists of Ease of package and Ease of freedom.
Constructive ease is for a garment’s outer volume, Ease of freedom is for a garment’s inner volume.
EC = EP + EF
We used one layer of insulation material for our garment, total density is 60 g/m2.
EASE OF PACKAGE (EP) = 2.0 CM (may differ according to a material type).
Ease of freedom (EF):
Bust-line – 30,4 cm.
Hips-line – 28,0 cm.
Shoulders – 20,7 cm (for all sizes in the height 152-158)
21,4 cm (for all sizes in the height 158-164)
21,9 cm (for all sizes in the height 164-170)
22,7 cm (for all sizes in the height 170-176)
23,4 cm (for all sizes in the height 176-182).
Garment Length Measurements, cm
|
Size |
38 |
40 |
42 |
44 |
46 |
48 |
50 |
52 |
54 |
56 |
|
Finished back length along the center back seam (Option 1 - COAT) |
102,2-108,4 |
102,3-114,7 |
102,3-114,7 |
102,4-114,8 |
102,4-114,8 |
102,5-114,9 |
102,5-114,9
|
102,6-115,0
|
102,6-115,0
|
102,7-115,1
|
|
Finished back length along the center back seam (Option 2 - JACKET) |
73,6-76,8 |
73,7-80,1 |
73,7-80,1 |
73,7-80,1 |
74,5-80,9 |
75,1-81,5 |
75,1-81,5 |
75,1-81,5 |
76,4-82,8 |
76,4-82,8 |
|
Finished sleeve length (including cuff) |
51,9-55,9 |
52,1-60,0 |
52,3-60,2 |
52,5-60,4 |
52,8-60,6 |
53,0-60,8 |
53,2-61,0 |
53,4-61,2 |
53,7-61,4 |
53,9-61,6 |
Fabric suggestion:
Main fabric. We recommend to use for this garment soft, average density and thin rain wear and coat fabrics; membrane-coated rain wear fabrics; waterproof coat fabrics. You also can use a ready made quilted rain wear fabrics.
Lining material. For membrane-coated fabrics use a lining cloth from synthetic fibers, for coat and rain wear fabrics use a lining cloth from synthetic, blended and natural fibers.
Insulation. To insulate the garment we recommend to use a new generation synthetic insulation materials with protective layers on its both sides. For example you can use a 60-100 g/m2 density ISOSOFT 34.
Interfacing materials. For better quality of sewing, we recommend to use the interfacing material and fusible facing straightener. For example, you may use 18 g/m2 density 150 cm, width woven interfacing. For better sewing quality, we recommend strengthening some details with a feasible facing straightener of 64 g/m2 and with the width of 90 cm.
The density of the interfacing material depends on the main fabric density.
Amount of Fabrics (in metres):
|
Size |
38 |
40 |
42 |
44 |
46 |
48 |
50 |
52 |
54 |
56 |
|
OPTION 1. COAT |
||||||||||
|
Main fabric, wide 140 cm |
3,10-3,20 |
3,20-3,45 |
3,25-3,50 |
3,35-3,55 |
3,40-3,70 |
3,50-3,75 |
3,60-3,85 |
3,65-3,90 |
3,70-4,00 |
3,80-4,05 |
|
Lining fabric, wide 140 cm |
1,55-1,65 |
1,55-1,75 |
1,55-1,75 |
1,55-1,75 |
1,60-1,80 |
1,60-1,80 |
1,60-1,80 |
1,85-2,15 |
1,90-2,15 |
1,95-2,30 |
|
Insulation material (60-100 g/m2; width 140 cm) |
2,25-2,35 |
2,25-2,50 |
2,30-2,55 |
2,40-2,65 |
2,50-2,70 |
2,55-2,80 |
2,60-2,85 |
2,60-2,90 |
2,65-2,95 |
2,75-2,95 |
|
OPTION 2. JACKET |
||||||||||
|
Main fabric, wide 140 cm |
2,75-2,85 |
2,85-3,05 |
2,90-3,10 |
2,95-3,15 |
3,05-3,30 |
3,10-3,35 |
3,20-3,40 |
3,25-3,50 |
3,35-3,55 |
3,40-3,60 |
|
Lining fabric, wide 140 cm |
1,55-1,65 |
1,55-1,75 |
1,55-1,75 |
1,55-1,75 |
1,60-1,80 |
1,60-1,80 |
1,60-1,80 |
1,90-2,10 |
1,90-2,15 |
2,00-2,30 |
|
Insulation material (60-100 g/m2; width 140 cm) |
1,85-1,95 |
1,90-2,05 |
1,95-2,10 |
1,95-2,15 |
2,05-2,20 |
2,10-2,30 |
2,15-2,30 |
2,20-2,40 |
2,25-2,40 |
2,25-2,45 |
|
FOR BOTH OPTIONS |
||||||||||
|
Interfacing (density 18 g/m2; width 150 cm) |
0,05 |
0,05 |
0,05 |
0,05 |
0,05 |
0,05 |
0,05 |
0,05 |
0,05 |
0,05 |
|
Cord with the diameter of 8-12 mm |
3,80 |
3,90 |
3,95 |
4,05 |
4,15 |
4,20 |
4,30 |
4,40 |
4,45 |
4,55 |
|
Reps tape with a width of 15-20 mm |
0,80 |
0,85 |
0,85 |
0,85 |
0,85 |
0,85 |
0,85 |
0,85 |
0,85 |
0,90 |
|
Fusible facing straightener with the density of 64 gr/m2; width of 90 cm |
0,50 |
0,50 |
0,50 |
0,50 |
0,50 |
0,50 |
0,50 |
0,50 |
0,50 |
0,50 |
Attention! Given exact fabric consumption can be used only when pattern details are placed on a fabric sheet close to each other. All pattern details should be arranged on an opened fabric sheet strictly on grain in one direction, each pattern piece must be cut out only once.
Garment accessories:
01. Buttons with the diameter of 12 mm – 5 pcs.
02. Snap buttons with the diameter of 12.5-15 mm – 2 pcs.
03. Grommets with the diameter of 10 mm – 6 pcs.
04. Close-end metal zipper #5, 20 cm long - 4 pc. (for the pocket).
05. Open-end central zipper #5 – 1 pc. (for COAT)
— long 70,0 сm (for all sizes in the height 152-158)
— long 75,0 сm (for all sizes in the height 158-164 and 164-170)
— long 80,0 сm (for all sizes in the height 170-176 and 176-182)
06. Open-end central zipper #5 – 1 pc. (for JACKET)
— long 75,0 сm (for all height in the sizes 38-40)
— long 75,0 сm (for all height in the sizes 42-52)
— long 80,0 сm (for all height in the sizes 54-56).
Pattern is given with seam allowances.
Detailed sewing instruction with step-by-step photos of sewing is attached to the pattern in the kit.
Degree of difficulty - "Advanced”.
The photos shows a coat and jacket sewed at the GRASSER for pattern №1001.
Model Kiki is wearing a size 42. Model parameters: Bust-line: 84 cm, Waist-line: 61,5 cm, Hips: 94 cm, Height: 177 cm.
Model Yana is wearing a size 42. Model parameters: Bust-line: 82 cm, Waist-line: 60,5 cm, Hips: 90 cm, Height: 173 cm.
The images also shows: leggings on pattern №974, sweater pattern №702
For sewing you will need the following equipment:
- Multipurpose sewing machine;
- An iron with or without steam;
- Regular presser foot;
- Hinged cording foot;
- Wooden iron;
- Ironing desk or console table;
- Hand needle for basting;
- Machine needles MICROTEX (extra sharp) №70-80 for the main fabric;
- Machine needles №70-80 for the lining;
- Paper scissors;
- Scissors for textile cutting;
- Snaps pressing machine to install accessories grommets and press studs, depending on the diameter.
The pattern in your order will be in two print options:
1. For printing on A4/Letter. You need to print the pattern on a regular printer on A4/Letter sheets, then glue the sheets, cut the pattern and you can sew!
A test square for checking the A4/Letter print scale is located on the first sheet of the pattern file.
2. For printing on a large format plotter.
A test square for checking the plotter scale is located on the pattern sheet.
