Coat and jacket with insulation, pattern №713

Sizes:

  • size 38, height 152-158
  • size 38, height 158-164
  • size 38, height 164-170
  • size 40, height 152-158
  • size 40, height 158-164
  • size 40, height 164-170
  • size 40, height 170-176
  • size 40, height 176-182
  • size 42, height 152-158
  • size 42, height 158-164
  • size 42, height 164-170
  • size 42, height 170-176
  • size 42, height 176-182
  • size 44, height 152-158
  • size 44, height 158-164
  • size 44, height 164-170
  • size 44, height 170-176
  • size 44, height 176-182
  • size 46, height 152-158
  • size 46, height 158-164
  • size 46, height 164-170
  • size 46, height 170-176
  • size 46, height 176-182
  • size 48, height 152-158
  • size 48, height 158-164
  • size 48, height 164-170
  • size 48, height 170-176
  • size 48, height 176-182
  • size 50, height 152-158
  • size 50, height 158-164
  • size 50, height 164-170
  • size 50, height 170-176
  • size 50, height 176-182
  • size 52, height 152-158
  • size 52, height 158-164
  • size 52, height 164-170
  • size 52, height 170-176
  • size 52, height 176-182
  • size 54, height 152-158
  • size 54, height 158-164
  • size 54, height 164-170
  • size 54, height 170-176
  • size 54, height 176-182
  • size 56, height 152-158
  • size 56, height 158-164
  • size 56, height 164-170
  • size 56, height 170-176
  • size 56, height 176-182
  • -

Size:

  • 38
  • 40
  • 42
  • 44
  • 46
  • 48
  • 50
  • 52
  • 54
  • 56

Height:

  • 152-158
  • 158-164
  • 164-170
  • 170-176
  • 176-182
$11

After payment, links for downloads of patterns are sent to your e-mail. For registered users download links are also available in personal account in the section "My Orders".

Info

Comments

Questions

Use the Test Square to adjust the print scale! A test square for checking the A4 scale is located on the first sheet of the A4 pattern file. The test square for checking the plotter scale is located on the pattern sheet in the plotter file.


Pattern of coat and jacket. The coat/jacket of medium volume with the straight silhouette, the coat length is just above the ankle, the jacket length is below the hip line, with a removable hood, with insulation and lining. The front has front side seams extending from the shoulder seam to the garment bottom; with a central facing clasp on a split, single-slider/double-slider zipper tape, the facing is with a clasp for 12(coat)/7 (jacket) buttons and an internal windproof placket. The back has back side seams extending from the shoulder seam to the bottom of the garment.

The garment has the set-in, long, double-seam sleeve. The neckband has 2 snaps. The hood is helmet-shaped, with a cut-off central part, the front edge of the hood contains the hidden drawstring with a smooth adjustment of the fit using a flat cord. To bring the ends of the cord to the front side, grommets are installed at the front edge of the hood at the level of the chin. The hood is fastened at the garment neck with 6 button loops and 6 buttons.

Patterns of coats and jackets are located in different files to save printing. The files for the top and lining of the jacket are located in additional channels, the files must be downloaded from separate links located in the order.


General increases, laid in the pattern:

*Constructive ease (Ec)*: Bust-line: 23,5 см; Waist-line: 49,0 см; Hips-line:20,5 см; Shoulders:  15,0 см.

*Ease of package (Ep)*: Bust-line: 6,0 см; Waist-line: 6,0 см; Hips-line: 6,0 см; Shoulders:  6,0 см.

*Ease of freedom (Ef): (Pay attention to this increase in order to estimate the garment volume!):

Bust-line: 17,5 см; Waist-line: 43,0 см; Hips-line: 14,5 см; Shoulders:  9,0 см.


*Constructive ease (Ec) – an integral part of a constructive segment that increases or decreases the size attribute, takes into account the thickness of the garment package, the freedom between the body and clothing, fashion direction, silhouette, physiological, hygienic and dynamic requirements, and is always included in the size parameters of the finished garment.

*Ease of package (Ep) – this value takes into account the thickness of all layers of clothes material worn on a person, which consists of ease for inner package, taking into account the underlying layers at designing clothes, and an ease of the outer package (package for designing garment).

*Ease of freedom (Ef) – ease that is necessary to ensure a person's freedom of breathing and movement, creating an air layer that regulates heat exchange and skin respiration under clothing.

*Ec = Ep + Ef



Finished back length along the center back seam, см.: 38 size: 124,6-140,6, 40 size: 124,8-140,8, 42 size: 125,0-141,0, 44 size:
125,2-141,2, 46 size: 125,4-141,4, 48 size: 125,6-141,6,  50 size: 125,8-141,8, 52 size: 125,8-141,8, 54 size: 126,2-142,2, 56 size: 126,4-142,4

Fabric suggestion: For this model we recommend to use thin raincoat, jacket fabrics, raincoat fabrics with the hydrophilic membrane; the new generation synthetic insulation material with a protective layer on both sides, for example, ISOSOFT 34 200 g/m2. Lining fabrics - viscose, silk.

Furniture:

1. Two grommets (the inner diameter is 1 cm);

2. One plastic zipper tape with the length of 70-80 cm for the coat, 65-70 cm for the jacket.

3. Snaps with the diameter of 1,0-1,2 cm – 16 snaps for the coat; 11 snaps for the jacket;

4. Six buttons with the diameter of 0,8-1,0 cm (for the for removable hood).


Material consumption for coat:

Main fabric, wide 140 cm: 38 size: 5,35-5,60 м; 40-44 size: 5,45-5,60 м; 46,48 size: 5,45-5,80 м; 50 size: 5,70-6,05 м; 52 size: 5,7-6,10 м; 54,56 size: 5,80-6,10 м.

Lining fabric, wide 140 cm: 38-50 sizes: 1,95-2,20 м, 52-56 sizes: 2,85-3,15 м.

Insulation, wide 140см: 38-44 sizes: 3,90-4,20 м., 46-56 sizes: 4,30-4,50 м.


Material consumption for jacket:

Main fabric, wide 140 cm:  38,40 size: 4,30-4,35 м; 42 size: 4,30-4,45 м; 44 size: 4,55-4,70 м; 46 size: 4,60-4,75 м; 48 size: 4,65-4,75 м; 50,52 size: 4,70-4,85 м; 54 size: 4,75-4,85 м; 56 size: 4,75-4,90 м.

Lining fabric, wide 140 cm: 38-50 sizes: 1,50-1,70 м, 52-56 sizes: 1,80-1,95 м.

Insulation, wide 140см: 38-44 sizes: 3,10-3,30 м, 46-56 sizes: 3,30-3,50 м.


Pattern is given with seam allowances.

Degree of difficulty - “Advanced”


The photos shows a coat and jacket sewed at the GRASSER  for pattern № 713

Model is wearing a size 42, height 170-176.  Model parameters: Bust-line: 85, waist-line: 63, Hips: 90, height 175.


The photo images also show:  dress on pattern №712


We want the work with the Grasser patterns to bring you pleasure, and the sewing process to be understandable, so a file with a very detailed sewing instruction is attached to the pattern. It covers all stages of the work on the garment, with step-by-step SEWING PHOTOS!

Also there are detailed information of the necessary consumption of fabric, materials and accessories in the instruction.


Описание пошива с лого_1.jpg


For sewing you will need the following equipment:

  • Multipurpose sewing machine;
  • An iron with or without steam;
  • Regular presser foot;
  • Sleeve board;
  • Wooden iron;
  • Ironing desk or console table;
  • Hand needle for basting;
  • Machine needles №90 and №100;
  • Paper scissors;
  • Scissors for textile cutting.


The pattern in your order will be in two print options:

1. For printing on A4. You need to print the pattern on a regular printer on A4 sheets, then glue the sheets, cut the pattern and you can sew!

A test square for checking the A4 print scale is located on the first sheet of the pattern file.


2. For printing on a large format plotter. Details of coat for size 56 are located on 2 sheets 60*322 см.  Details of coat lining for size 56 are located on sheet  60*149 см.

Details of jacket for size 56 are located on 2 sheets 60*245 см.  Details of jacket lining for size 56 are located on sheet  60*223 см.


A test square for checking the plotter scale is located on the pattern sheet.
