Jacket, pattern №1169

Sizes:

  • size 38, height 152-158
  • size 38, height 158-164
  • size 38, height 164-170
  • size 40, height 152-158
  • size 40, height 158-164
  • size 40, height 164-170
  • size 40, height 170-176
  • size 40, height 176-182
  • size 42, height 152-158
  • size 42, height 158-164
  • size 42, height 164-170
  • size 42, height 170-176
  • size 42, height 176-182
  • size 44, height 152-158
  • size 44, height 158-164
  • size 44, height 164-170
  • size 44, height 170-176
  • size 44, height 176-182
  • size 46, height 152-158
  • size 46, height 158-164
  • size 46, height 164-170
  • size 46, height 170-176
  • size 46, height 176-182
  • size 48, height 152-158
  • size 48, height 158-164
  • size 48, height 164-170
  • size 48, height 170-176
  • size 48, height 176-182
  • size 50, height 152-158
  • size 50, height 158-164
  • size 50, height 164-170
  • size 50, height 170-176
  • size 50, height 176-182
  • size 52, height 152-158
  • size 52, height 158-164
  • size 52, height 164-170
  • size 52, height 170-176
  • size 52, height 176-182
  • size 54, height 152-158
  • size 54, height 158-164
  • size 54, height 164-170
  • size 54, height 170-176
  • size 54, height 176-182
  • size 56, height 152-158
  • size 56, height 158-164
  • size 56, height 164-170
  • size 56, height 170-176
  • size 56, height 176-182
  • -

Size:

  • 38
  • 40
  • 42
  • 44
  • 46
  • 48
  • 50
  • 52
  • 54
  • 56

Height:

  • 152-158
  • 158-164
  • 164-170
  • 170-176
  • 176-182
$10

After payment, links for downloads of patterns are sent to your e-mail. For registered users download links are also available in personal account in the section "My Orders".

Info

Comments

Questions

Pattern of a jacket. Regular fit, straight, lined and insulated jacket with the length that falls at the hips. Centre front snap fastener closure. The front features chest pockets and patch pockets at the bottom. The neckline, hem of the front and the front edge are finished with facings and plackets. Full-length set-in sleeve with two seams and length below wrist. The hem of the sleeve is finished with a band. The neckline is round.


Eases added to a pattern, cm:

CONSTRUCTIVE EASE (EC)*:

Bust-line: 20,0 cm. Hips-line: 22,4 cm. Shoulders: 13,0 cm.

Constructive ease consists of ease of package and ease of freedom.

Constructive ease is for a garment’s outer volume, ease of freedom is for a garment’s inner volume.

EF = EC - EP

We used 100 g/m2 density insulation material for our garment. Ease of package was 3.0 cm (EP)*: May differ according to a material type.

Ease of freedom (EF):

Bust-line: 17,0 cm. Hips-line: 19,4 cm. Shoulders: 10,0 cm.


Garment Length Measurementscm:

Size

38

40

42

44

46

48

50

52

54

56

Finished back length along the center back

59,0-62,1

59,1-65,4

59,2-65,5

59,3-65,6

59,4-65,7

59,5-65,8

59,6-65,9

59,7-66,0

59,8-66,1

59,9-66,2

Finished sleeve length

58,0-61,7

58,2-65,8

58,4-66,0

58,6-66,2

58,8-66,4

59,0-66,6

59,2-66,8

59,4-67,0

59,6-67,2

59,8-67,4


Fabric suggestion:

Main fabric. We recommend this garment soft, light-weight or midweight raincoat and parka fabrics: membrane outdoor fabrics, outdoor fabrics with waterproof coating.

Lining material. For lining we recommend synthetic lining fabrics for membrane fabrics and natural, synthetic and blended lining fabrics for other outdoor fabrics.

Insulation. We recommend a new-generation synthetic insulation with double-side coating such as ISOSOFT 34 weight 100 gsm.

Interfacing materials. For better tailoring we recommend using a side booster with a non-adhesive density of 90 g/m2, a width of 90 cm.


Amount of Fabrics (in metres):

Size

38

40

42

44

46

48

50

52

54

56

Main fabric #1, wide 140 cm

1,15-1,20

1,15-1,25

1,15-1,30

1,20-1,30

1,20-1,35

1,20-1,35

1,25-1,40

1,25-1,40

1,25-1,40

1,30-1,40

Main fabric #2, wide 140 cm

0,70-0,75

0,70-0,80

0,75-0,80

0,80-0,85

Lining fabric, wide 140 cm

1,15-1,20

1,15-1,25

1,15-1,30

1,15-1,30

1,20-1,30

1,20-1,35

1,25-1,40

1,25-1,40

1,25-1,40

1,25-1,40

Insulation material (100 g/m2; width 140 cm)

1,40-1,45

1,45-1,55

1,50-1,60

1,50-1,65

1,55-1,70

1,60-1,75

1,65-1,80

1,70-1,80

1,75-1,85

1,75-1,90

Non-fusible facing straightener of 90 g/m2 and with the width of 90 cm

0,75-0,80

0,80-0,85

0,85-0,90

Attention! Given exact fabric consumption can be used only when pattern details are placed on a fabric sheet close to each other. All pattern details should be arranged on an opened fabric sheet strictly on grain in one direction, each pattern piece must be cut out only once.

Notions: Snap fastener, diameter 12.5-15 mm - 6 pcs.
Pattern is given with seam allowances.

Detailed sewing instruction with step-by-step photos of sewing is attached to the pattern in the kit.

Degree of difficulty - "Advanced"


The photos shows a jacket sewed at the GRASSER  for pattern №1169.

Model is wearing a size 42, height 170-176. Model parameters: Bust-line: 83 cm, Waist-line: 64.5 cm, Hips: 89.5 cm, Height: 177 cm.

The photo also shows: skirt on pattern №1158, turtleneck sweater on pattern №1074, shirt on pattern №1104, tie on pattern №1105, dress on pattern №1170dress on pattern №1176.



For sewing you will need the following equipment:

1.         Multipurpose sewing machine;
2.       An iron with or without steam;
3.       Regular presser foot;
4.       Wooden iron;
5.       Ironing desk or console table;
6.       Hand needle for basting;
7.       Machine needles MICROTEX (extra sharp for raincoat fabrics) №70-80 for the main fabric;
8.       Machine needles №70-75 for the lining;
9.       Paper scissors;
10.    Scissors for textile cutting;
11.      Snaps pressing machine to install accessories and press studs, depending on the diameter.

The pattern in your order will be in two print options:

1. For printing on A4/Letter. You need to print the pattern on a regular printer on A4/Letter sheets, then glue the sheets, cut the pattern and you can sew!

A test square for checking the A4/Letter print scale is located on the first sheet of the pattern file.

2. For printing on a large format plotter.

A test square for checking the plotter scale is located on the pattern sheet.
