Coat, pattern №1066

Coat, pattern №1066

Price

$11

PDF sewing pattern of coat.

The price is for each size. You can buy only each size separately.

Pattern in your order will be in two print versions: by printer (on A4/Letter sheets) and by plotter (on large-scale sheets)

After payment, links for downloads of patterns are sent to your e-mail. For registered users download links are also available in personal account in the section "My Orders".

The size of this pattern is from 38 to 56 ( it's Russian sizes, see size chart )

The pattern in each size is in five ranges of height: 152-158, 158-164, 164-170, 170-176, 176-182 cm.

Buy carefully - choose the right size.

Sizes

size 38, height 152-158
size 38, height 158-164
size 38, height 164-170
size 40, height 152-158
size 40, height 158-164
size 40, height 164-170
size 40, height 170-176
size 40, height 176-182
size 42, height 152-158
size 42, height 158-164
size 42, height 164-170
size 42, height 170-176
size 42, height 176-182
size 44, height 152-158
size 44, height 158-164
size 44, height 164-170
size 44, height 170-176
size 44, height 176-182
size 46, height 152-158
size 46, height 158-164
size 46, height 164-170
size 46, height 170-176
size 46, height 176-182
size 48, height 152-158
size 48, height 158-164
size 48, height 164-170
size 48, height 170-176
size 48, height 176-182
size 50, height 152-158
size 50, height 158-164
size 50, height 164-170
size 50, height 170-176
size 50, height 176-182
size 52, height 152-158
size 52, height 158-164
size 52, height 164-170
size 52, height 170-176
size 52, height 176-182
size 54, height 152-158
size 54, height 158-164
size 54, height 164-170
size 54, height 170-176
size 54, height 176-182
size 56, height 152-158
size 56, height 158-164
size 56, height 164-170
size 56, height 170-176
size 56, height 176-182
-

Add to Cart

Create an Account or Login to Add to Wish list

How to determine your size

How to download a pattern

How to print a pattern

All documents, multimedia and texts posted on www.en-grasser.com are the intellectual property of GRASSER LLC. Patterns and master classes are provided to buyers for personal use. Resale of patterns and master classes is prohibited. Public offering of our products and links to their downloading - on the Internet, social networks and in the media - is a violation and carries a penalty in accordance to applicable law.

Coat pattern. A free volume coat with a straight silhouette, and a length below the calf, is insulated and lined, and has a hood. The closure is a central zipper tape, it is finished with an internal and external underlap plackets. The external placket is stitched on with a clasp with 5 snaps. The upper part of the left front has a vertical welt pocket with the zipper tape. The lower part of the front has welt pockets with the stitched in ends and with the flaps. There is a snap closure on the internal side of the flap. The back is with a center seam and an attached yoke. There is a drawstring at the bottom line of the front and back on the internal side of the garment to adjust the fit using the cord and stoppers. The cord is brought to the wrong side through the grommets, which are located on the side seams. The shoulder line is lowered by 9.7-13.3 cm (depending on the garment size). The sleeves are sewn in, and of the full length, with the bottom and elbow seams and the attached downside part. There is a strap on the downside part of the sleeve. On the internal side of the strap, there is a clasp with 2 snaps to adjust the volume at the sleeve bottom. The sleeve is completed with the internal knitted cuff. The round shaped neckline is finished with a hood. The hood is of moderate volume, with a central part and a wide lining along the front edge. There is a strap on the central part of the hood to adjust the volume.

Eases added to a pattern, cm:

CONSTRUCTIVE EASE (EC)*:

Bust-line – 48,0 cm.

Hips-line – 43,0 cm.

Shoulders – 34,8 cm.

Constructive ease consists of ease of package and ease of freedom. Constructive ease is for a garment’s outer volume, ease of freedom is for a garment’s inner volume.

EC = EP + EF

We used 200 g/m2 density insulation material for our garment.

EASE OF PACKAGE WAS 5.0CM (EP)*:

EASE OF FREEDOM (EF): (may vary depending on a type of insulation material).

Bust-line – 43,0 cm.

Hips-line – 38,0 cm.

Shoulders – 29,8 cm.

Garment Length Measurements, cm:

Size	38	40	42	44	46	48	50	52	54	56
Finished back length along the center back seam	110,8-119,0	110,8-127,2	110,9-127,3	110,9-127,3	111,0-127,4	111,0-127,4	111,1-127,5	111,1-127,5	111,2-127,6	111,2-127,6
Finished sleeve length	52,6-56,5	52,5-60,1	52,4-60,0	52,3-59,9	52,2-59,8	52,1-59,7	52,0-59,6	51,9-59,5	51,8-59,4	51,7-59,3

Fabric suggestion:

Main fabric. For this model, we recommend using raincoat, jacket fabrics; raincoat fabrics with a membrane; raincoat, jacket fabrics with impregnation.

Lining material. As a lining for membrane fabrics, we recommend using a lining fabric that is made of synthetic fibers, for raincoat and jacket fabrics - a lining fabric made of synthetic, mixed and natural fibers. As a lining for the front pockets, we recommend using fleece with a density of 190 g/m2.

Insulation. To insulate the garment, we recommend using synthetic insulation materials of a new generation with a protective layer on both sides, for example, ISOSOFT 34 200 g/m2 and 100 g/m2.

Interfacing materials. For better quality of sewing, we recommend to use the interfacing material. For example, you may use 39 g/m2 density 150 cm, width woven interfacing. The density of the interfacing material depends on the main fabric density. For better tailoring we recommend using a side booster with a non-adhesive density of 50 g/m2, a width of 90 cm.

Size	38	40	42	44	46	48	50	52	54	56
Main fabric, wide 140 cm	3,25-3,40	3,30-3,60	3,40-3,70	3,40-3,75	3,50-3,80	3,55-3,95	3,60-4,00	3,70-4,05	3,75-4,10	3,80-4,15
Lining fabric, wide 140 cm	1,85-2,05	1,95-2,20	1,95-2,20	2,00-2,25	2,05-2,35	2,25-2,55	2,30-2,60	2,40-2,70	2,45-2,75	2,45-2,80
Insulation material (200 g/m2; width 140 cm)	2,50-2,65	2,50-2,85	2,55-2,90	2,60-2,90	2,70-3,00	2,70-3,05	2,75-3,10	2,80-3,10	2,85-3,20	2,90-3,20
Rib knit fabric (kashkorse or ribana), wide 100 cm	0,30
Fleece, wide 150 cm	0,35
Non-fusible facing straightener of 50 g/m2 and with the width of 90 cm	1,30-1,45	1,30-1,45	1,30-1,45	1,30-1,45	1,30-1,45	1,30-1,45	1,30-1,45	1,30-1,45	1,30-1,45	1,30-1,45
Interfacing (density 39 g/m2; width 150 cm)	0,40
Elastic band, 3.5 cm wide	1,30-1,35	1,35-1,40	1,35-1,40	1,35-1,40	1,35-1,45	1,40-1,45	1,40-1,45	1,40-1,45	1,40-1,50	1,45-1,50
Flat cord, 0.3 cm wide	1,35	1,40	1,40	1,45	1,50	1,55	1,60	1,60	1,65	1,70

Attention! Given exact fabric consumption can be used only when pattern details are placed on a fabric sheet close to each other. All pattern details should be arranged on an opened fabric sheet strictly on grain in one direction, each pattern piece must be cut out only once.

Notions:
1. Snap with a diameter of 12.5 - 15.0 mm - 11 pcs.
2. Detachable zipper of type 5 and with the length of
3. 85 cm - 1 pcs (for all sizes of the height 152-158 and 158-164).
4. 90 cm - 1 pcs (for all sizes of the height 164-170, 170-176, and 176-182).
5. Undetachable metal zipper of type 5 with the length of 18 cm - 1 pcs. (for a chest pocket)
6. “Twisted” plastic zipper of type 3 with the length of 18 cm - 1 pcs. (internal pocket)
7. Grommets (with the diameter of 5 mm) - 4 pcs.
8. Plastic stopper with 2 holes - 2 pcs.
9. Half-ring/Frame with the internal width of 25 mm - 2 pcs. (for a hood).
10. Frame-regulator with the internal width of 35 mm - 2 pcs.
11. Frame with the internal width of 35 mm - 2 pcs.

Pattern is given with seam allowances.

Detailed sewing instruction with step-by-step photos of sewing is attached to the pattern in the kit.

Degree of difficulty - «Advanced».

The photos shows a coat sewed at the GRASSER for pattern №1066.

Model is wearing a size 42. Model parameters: Model parameters: Bust-line: 81 cm, Waist-line: 61 cm, Hips: 91 cm, Height: 173 cm.

The photo also shows: longsleeve on pattern №889, stirrup leggings on pattern №890.

For sewing you will need the following equipment:

1. Multipurpose sewing machine;
2. An iron without steam;
3. Regular presser foot;
4. Wooden iron;
5. Ironing desk or console table;
6. Hand needle for basting;
7. Machine needles MICROTEX (extra sharp) №80 for the main fabric;
8. Machine needles №80-90 for the lining;
9. Paper scissors;

10. Scissors for textile cutting;
11. Snaps pressing machine to install accessories grommets and press studs, depending on the diameter.

The pattern in your order will be in two print options:

1. For printing on A4/Letter. You need to print the pattern on a regular printer on A4/Letter sheets, then glue the sheets, cut the pattern and you can sew!

A test square for checking the A4/Letter print scale is located on the first sheet of the pattern file.

2. For printing on a large format plotter.

A test square for checking the plotter scale is located on the pattern sheet.
