Jacket, pattern №1106

Jacket, pattern №1106

Price

$10

PDF sewing pattern of jacket.

The price is for each size. You can buy only each size separately.

Pattern in your order will be in two print versions: by printer (on A4/Letter sheets) and by plotter (on large-scale sheets)

After payment, links for downloads of patterns are sent to your e-mail. For registered users download links are also available in personal account in the section "My Orders".

The size of this pattern is from 38 to 56 ( it's Russian sizes, see size chart )

The pattern in each size is in five ranges of height: 152-158, 158-164, 164-170, 170-176, 176-182 cm.

Buy carefully - choose the right size.

Sizes

size 38, height 152-158
size 38, height 158-164
size 38, height 164-170
size 40, height 152-158
size 40, height 158-164
size 40, height 164-170
size 40, height 170-176
size 40, height 176-182
size 42, height 152-158
size 42, height 158-164
size 42, height 164-170
size 42, height 170-176
size 42, height 176-182
size 44, height 152-158
size 44, height 158-164
size 44, height 164-170
size 44, height 170-176
size 44, height 176-182
size 46, height 152-158
size 46, height 158-164
size 46, height 164-170
size 46, height 170-176
size 46, height 176-182
size 48, height 152-158
size 48, height 158-164
size 48, height 164-170
size 48, height 170-176
size 48, height 176-182
size 50, height 152-158
size 50, height 158-164
size 50, height 164-170
size 50, height 170-176
size 50, height 176-182
size 52, height 152-158
size 52, height 158-164
size 52, height 164-170
size 52, height 170-176
size 52, height 176-182
size 54, height 152-158
size 54, height 158-164
size 54, height 164-170
size 54, height 170-176
size 54, height 176-182
size 56, height 152-158
size 56, height 158-164
size 56, height 164-170
size 56, height 170-176
size 56, height 176-182
-

Add to Cart

Create an Account or Login to Add to Wish list

How to determine your size

How to download a pattern

How to print a pattern

All documents, multimedia and texts posted on www.en-grasser.com are the intellectual property of GRASSER LLC. Patterns and master classes are provided to buyers for personal use. Resale of patterns and master classes is prohibited. Public offering of our products and links to their downloading - on the Internet, social networks and in the media - is a violation and carries a penalty in accordance to applicable law.

Jacket pattern. Loose fit, straight, lined jacket with the length below the hip line. The fastening is on the centre front with 2 buttons and 2 buttonholes. No side seam. The garment is designed with a side piece instead. The front pieces feature two darts and two pockets. The first dart of the front ends up at the neckline and is covered with the lapel. The other dart is drafted by combining the bust dart and the waist dart and it ends up at the pocket seam. The jetted pocket is designed with welts and a flap. A chest pocket is added on the left front. The chest pocket is slanted, tilted and has a welt with secured ends. The back is with a centre seam. The princess seams of the back are designed with vents. The set-in two-seam sleeves have a vent in the elbow seam. The notch lapel is designed with an attached collar stand.

Eases added to a pattern, cm: Bust-line: 37,0 cm. Hips-line: 27,6 cm. Shoulders: 15,0 cm.

Garment Length Measurements, cm:

Size	38	40	42	44	46	48	50	52	54	56
Finished back length along the center back seam	73,6-77,8	73,7-82,0	73,8-82,1	73,9-82,2	74,0-82,3	74,1-82,4	74,2-82,5	74,3-82,6	74,4-82,7	74,5-82,8
Finished sleeve length	59,9-63,8	60,0-67,6	60,1-67,7	60,2-67,8	60,3-67,9	60,4-68,0	60,5-68,1	60,6-68,2	60,7-68,3	60,8-68,4

Fabric suggestion:

Main fabric. For this garment we recommend suiting fabrics, which are easy to press (some pieces are designed with easing of their edges). The fabric can be natural, synthetic or blended.

Lining material. As a lining use the fabrics with density and plasticity suitable for the shell fabric, made out of natural, synthetic or blended fibre.

Interfacing materials. For better quality of sewing, we recommend to use the interfacing material and fusible facing straightener. For example, you may use 55 g/m2 and 39 g/m2 density 150 cm, width woven interfacing.

The density of the interfacing material depends on the main fabric density.

The following interfacing is recommended:

— Non-fusible facing straightener of 90 g/m2 and with the width of 90 cm;

— Non fusible wadding 212 gsm 160 cm wide;

— Sleeve head roll fabric Ismalin DICHT, 1.2 мм, 90 cm wide.

Amount of Fabrics (in metres):

Size	38	40	42	44	46	48	50	52	54	56
Main fabric, wide 140 cm	1,80-1,85	1,85-1,95	1,85-2,05	1,90-2,10	1,95-2,10	2,00-2,20	2,05-2,25	2,10-2,30	2,15-2,35	2,20-2,40

Size	38	40	42	44	46	48	50	52	54	56
Lining fabric, wide 140 cm	1,35-1,45	1,35-1,50	1,40-1,55	1,40-1,55	1,45-1,60	1,45-1,60	1,45-1,60	1,50-1,70	1,55-1,75	1,60-1,75

Size	38	40	42	44	46	48	50	52	54	56
Interfacing (density 55 g/m2; width 150 cm)	0,90	0,95	0,95	0,95	0,95	1,00	1,00	1,00	1,00	1,00

Size

Interfacing (density 39 g/m2; width 150 cm)

1,55

1,55-1,75

1,60-1,80

1,65-1,80

1,70-1,80

1,70-1,85

1,75-1,90

Size	38	40	42	44	46	48	50	52	54	56
Non-fusible facing straightener of 90 g/m2 and with the width of 90 cm	0,35	0,35-0,40	0,35-0,40	0,35-0,40	0,40	0,40	0,40	0,40	0,40	0,40

Size	38	40	42	44	46	48	50	52	54	56
Non fusible wadding 212 gsm 160 cm wide	0,45	0,45-0,50	0,45-0,50	0,45-0,50	0,50	0,50-0,55	0,50-0,55	0,50-0,55	0,50-0,55	0,50-0,55

Size	38	40	42	44	46	48	50	52	54	56
Sleeve head roll fabric Ismalin DICHT, 1.2мм, 90cm wide	0,25	0,25	0,25	0,25	0,25	0,25	0,25	0,25	0,25	0,25

Size	38	40	42	44	46	48	50	52	54	56
Bias fusible tape with reinforcement stitches	4,05-4,15	4,10-4,30	4,15-4,40	4,20-4,45	4,25-4,50	4,35-4,55	4,40-4,60	4,45-4,65	4,50-4,75	4,55-4,80

Size	38	40	42	44	46	48	50	52	54	56
Fusible on grain tape	1,80	1,90	1,90	1,90	1,90	1,95	1,95	1,95	2,00	2,00

Attention! We give an exact fabric consumption for a tight layout scheme of the details, without the extra seam allowances for the fitting and rough cutting. All pattern details should be arranged on an opened fabric sheet strictly on grain in one direction, each pattern piece must be cut out only once.

Accessories:

1. Button 22-25 mm in diameter - 2 pcs.

2. Button 12-15 mm in diameter - 8 pcs.

3. Shoulder pads 10 mm thick - 1 pair.

Pattern is given with seam allowances.

Detailed sewing instruction with step-by-step photos of sewing is attached to the pattern in the kit.

Degree of difficulty - «Advanced».

The photos shows a jacket sewed at the GRASSER for pattern №1106.

Model is wearing a size 42. Model parameters: Bust-line: 81 cm, Waist-line: 61 cm, Hips: 92 cm, Height: 174 cm.

The photo also shows: blouse on pattern №1104, blouse on pattern №859, trousers on pattern №998, vest on pattern №1114, trousers on pattern №1163, shirt on pattern №947.

For sewing you will need the following equipment:
1.      Multipurpose sewing machine;
2.      An iron with or without steam;
3.      Regular presser foot;
4.      Hinged cording foot;
5.      Wooden iron;
6.      Ironing desk or console table;
7.      Hand needle for basting;
8.      Machine needles №80-90 for the main fabric;
9.      Machine needles №70 for the lining;
10. Paper scissors;
11. Scissors for textile cutting.

The pattern in your order will be in two print options:

1. For printing on A4/Letter. You need to print the pattern on a regular printer on A4/Letter sheets, then glue the sheets, cut the pattern and you can sew!

A test square for checking the A4/Letter print scale is located on the first sheet of the pattern file.

2. For printing on a large format plotter.

A test square for checking the plotter scale is located on the pattern sheet.
