Trench coat, pattern №1003

Trench coat, pattern №1003

Price

$10

PDF sewing pattern of trench coat.

The price is for each size. You can buy only each size separately.

Pattern in your order will be in two print versions: by printer (on A4/Letter sheets) and by plotter (on large-scale sheets)

After payment, links for downloads of patterns are sent to your e-mail. For registered users download links are also available in personal account in the section "My Orders".

The size of this pattern is from 38 to 56 ( it's Russian sizes, see size chart )

The pattern in each size is in five ranges of height: 152-158, 158-164, 164-170, 170-176, 176-182 cm.

Buy carefully - choose the right size.

Sizes

size 38, height 152-158
size 38, height 158-164
size 38, height 164-170
size 40, height 152-158
size 40, height 158-164
size 40, height 164-170
size 40, height 170-176
size 40, height 176-182
size 42, height 152-158
size 42, height 158-164
size 42, height 164-170
size 42, height 170-176
size 42, height 176-182
size 44, height 152-158
size 44, height 158-164
size 44, height 164-170
size 44, height 170-176
size 44, height 176-182
size 46, height 152-158
size 46, height 158-164
size 46, height 164-170
size 46, height 170-176
size 46, height 176-182
size 48, height 152-158
size 48, height 158-164
size 48, height 164-170
size 48, height 170-176
size 48, height 176-182
size 50, height 152-158
size 50, height 158-164
size 50, height 164-170
size 50, height 170-176
size 50, height 176-182
size 52, height 152-158
size 52, height 158-164
size 52, height 164-170
size 52, height 170-176
size 52, height 176-182
size 54, height 152-158
size 54, height 158-164
size 54, height 164-170
size 54, height 170-176
size 54, height 176-182
size 56, height 152-158
size 56, height 158-164
size 56, height 164-170
size 56, height 170-176
size 56, height 176-182
-

Add to Cart

Create an Account or Login to Add to Wish list

How to determine your size

How to download a pattern

How to print a pattern

All documents, multimedia and texts posted on www.en-grasser.com are the intellectual property of GRASSER LLC. Patterns and master classes are provided to buyers for personal use. Resale of patterns and master classes is prohibited. Public offering of our products and links to their downloading - on the Internet, social networks and in the media - is a violation and carries a penalty in accordance to applicable law.

Trench coat pattern. Regular fit lined trench coat with slightly flared hem. Mid-calf length. A double-breasted front has two rows of buttonholes and buttons. The front features welted button-close pockets with topstitched ends. The left front is defined with a storm flap. The storm flap is secured to the front with a button and a buttonhole. The back is designed with a centre seam. A vent is sewn in the centre seam. The back is completed with a storm flap. The raglan sleeves have three seams: an upper seam, front seam and elbow seam. Detachable curved epaulettes are placed along the shoulder seam on the top of the sleeve. The epaulette is inserted through a loop and fastened with a button. A detachable strap with a buckle is placed in the lower part of the sleeve to adjust the sleeve volume. The strap is inserted through three loops and is placed 5 cm above the sleeve hem. The roll collar has an attached collar stand. The collar stand is fastened with a hook. The collar is completed with a throat latch. The throat latch is fastened with a buckle (on the right part of the collar) or with two buttonholes and two buttons (on the left part of the collar). The trench coat is designed with a detachable belt with a buckle. The belt is inserted through two belt loops sewn on the side seams. A keeper loop is affixed to the inner side of the belt near the buckle. Three D-rings are attached with straps to the lower edge of the belt.

Eases added to a pattern, cm:

Bust-line – 26,4 cm + model’s widening;

Hips-line – 18,3 cm + model’s widening;

Shoulders – 26,0 cm.

Garment Length Measurements, cm:

Size	38	40	42	44	46	48	50	52	54	56
Finished back length along the center back seam	107,3-115,4	107,4-123,7	107,5-123,8	107,6-123,9	107,7-124,0	107,8-124,1	107,9-124,2	108,0-124,3	108,1-124,4	108,2-124,5
Finished sleeve length from neckline	68,0-72,4	68,5-77,3	68,9-77,7	69,3-78,2	69,7-78,6	70,1-79,0	70,6-79,4	71,0-79,9	71,5-80,4	71,8-80,7

Fabric suggestion:

Main fabric. For this garment we recommend using twill fabrics with or without various coatings with or without waterproof surface of different weights and textures. The fabric can be natural, synthetic or blended.

Lining material. As a lining use the fabrics with density and plasticity suitable for the shell fabric, made out of natural, synthetic or blended fibre.

Interfacing materials. For a higher quality result we recommend using iron-on woven interfacing, iron-on or sew-on non-woven interfacing. Iron-on woven interfacing materials 18 gsm and 55 gsm 150 cm wide are required for the garment’s pieces interfacing. Select the right weight of the interfacing depending on your main fabric’s weight.

The following interfacing is recommended:

1. Fusible interfacing fabric 103 gsm.

2. Non-woven iron-on interfacing 30 gsm.

3. Non-woven sew-on interfacing 60 gsm.

Amount of Fabrics (in metres):

Size	38	40	42	44	46	48	50	52	54	56
Main fabric, wide 140 cm	2,90-3,10	3,00-3,30	3,00-3,40	3,05-3,45	3,15-3,50	3,20-3,55	3,30-3,65	3,40-3,70	3,40-3,80	3,50-3,85
Lining fabric, wide 140 cm	1,75-1,85	1,80-2,00	1,85-2,05	1,85-2,10	1,90-2,20	1,95-2,20	2,00-2,25	2,05-2,35	2,10-2,40	2,15-2,45
Interfacing (density 55 g/m2; width 150 cm)	1,10-1,15	1,10-1,25					1,10-1,25	1,15-1,30
Interfacing (density 18 g/m2; width 150 cm)	0,15
Fusible interfacing fabric 103 g/m2, wide 90 cm	0,25
Non-woven iron-on interfacing 30 g/m2, wide 90 cm	0,10
Non-woven sew-on interfacing 60 g/m2, wide 105 cm	0,25
Fusible on grain tape	1,05

LINING USED IN CLASSIC TRENCH COATS, FOR EXAMPLE, IN BURBERRY TRENCH COATS:

— Cotton lining fabric, medium weight and medium thickness, is used for the front and back.

— Silk twill fabrics, which may contain viscose fibre, are used for the sleeve pieces.

— Pocketing fabric is used for pocket lining. It may be natural fabrics or blends.

Size	38	40	42	44	46	48	50	52	54	56
Lining fabric, wide 140 cm (for the front and back)	1,25-1,30	1,25-1,40	1,25-1,40	1,25-1,40	1,25-1,55	1,40-1,70	1,55-1,90	1,75-2,10	1,95-2,30	2,00-2,30
Lining fabric, wide 140 cm (for the sleeve pieces)	0,80-0,85	0,80-0,90				0,85-0,90	0,85-0,95		0,90-0,95	0,95-1,00
Lining fabric, wide 140 cm (for pocket lining)	0,40

Attention! Given exact fabric consumption can be used only when pattern details are placed on a fabric sheet close to each other. All pattern details should be arranged on an opened fabric sheet strictly on grain in one direction, each pattern piece must be cut out only once.

Garment accessories:

1. Button 27-28 mm in diameter - 12 pcs.
2. Button 22 mm in diameter - 6 pcs.
3. Button 17-18 mm in diameter - 5 pcs.
4. Button 14-15 mm in diameter - 8 pcs.
5. Hook for the collar stand, metal, 25 mm wide - 1 pc.
6. Double-cap rivets, metal, 7 mm in diameter - 4 pcs.
7. Leather-covered metal buckle with inner width 50 mm - 1 pc (for the belt).
8. Leather-covered metal buckle with inner width 30 mm - 1 pc (for the sleeve strap).
9. Metal buckle with inner width 25 mm - 1 pc (for the throat latch).
10. Chain hanging loop, metal - 1 pc.
11. D-ring with the inner width 20 mm, metal - 3 pcs (for the D-ring holders).

Pattern is given with seam allowances.

Detailed sewing instruction with step-by-step photos of sewing is attached to the pattern in the kit.

Degree of difficulty - "Advanced”.

The photos shows a raincoat sewed at the GRASSER for pattern №1003.

Model is wearing a size 42. Model parameters: Bust-line: 84 cm, Waist-line: 61,5 cm, Hips: 94 cm, Height: 177 cm.

The images also shows: turtleneck sweater on pattern №913, trousers on pattern №885, coat on pattern №1011, turtleneck sweater on pattern №893.

For sewing you will need the following equipment:

1. Multipurpose sewing machine;
2. An iron with or without steam;
3. Regular presser foot;
4. Hinged cording foot;
5. Wooden iron;
6. Ironing desk or console table;
7. Hand needle for basting;
8. Machine needles №80-90 for the main fabric;
9. Machine needles №70-80 for the lining;
10. Paper scissors;
11. Scissors for textile cutting;
12. Snaps pressing machine to install accessories and polyteny dies depending on diameter.

The pattern in your order will be in two print options:

1. For printing on A4/Letter. You need to print the pattern on a regular printer on A4/Letter sheets, then glue the sheets, cut the pattern and you can sew!

A test square for checking the A4/Letter print scale is located on the first sheet of the pattern file.

2. For printing on a large format plotter.

A test square for checking the plotter scale is located on the pattern sheet.
