Coat, pattern №970

Sizes:

  • size 38, height 152-158
  • size 38, height 158-164
  • size 38, height 164-170
  • size 40, height 152-158
  • size 40, height 158-164
  • size 40, height 164-170
  • size 40, height 170-176
  • size 40, height 176-182
  • size 42, height 152-158
  • size 42, height 158-164
  • size 42, height 164-170
  • size 42, height 170-176
  • size 42, height 176-182
  • size 44, height 152-158
  • size 44, height 158-164
  • size 44, height 164-170
  • size 44, height 170-176
  • size 44, height 176-182
  • size 46, height 152-158
  • size 46, height 158-164
  • size 46, height 164-170
  • size 46, height 170-176
  • size 46, height 176-182
  • size 48, height 152-158
  • size 48, height 158-164
  • size 48, height 164-170
  • size 48, height 170-176
  • size 48, height 176-182
  • size 50, height 152-158
  • size 50, height 158-164
  • size 50, height 164-170
  • size 50, height 170-176
  • size 50, height 176-182
  • size 52, height 152-158
  • size 52, height 158-164
  • size 52, height 164-170
  • size 52, height 170-176
  • size 52, height 176-182
  • size 54, height 152-158
  • size 54, height 158-164
  • size 54, height 164-170
  • size 54, height 170-176
  • size 54, height 176-182
  • size 56, height 152-158
  • size 56, height 158-164
  • size 56, height 164-170
  • size 56, height 170-176
  • size 56, height 176-182
  • -

Size:

  • 38
  • 40
  • 42
  • 44
  • 46
  • 48
  • 50
  • 52
  • 54
  • 56

Height:

  • 152-158
  • 158-164
  • 164-170
  • 170-176
  • 176-182
$11

After payment, links for downloads of patterns are sent to your e-mail. For registered users download links are also available in personal account in the section "My Orders".

Info

Comments

Questions

Coat pattern. It’s a standard fit straight silhouette lined insulated lower-the-hips length coat. Coat is double-breasted. Upper front part of the coat features a vertical set-in welt pocket with sewn-on ends. Inner part of the welt features a snap button. Bottom front part features a patch pocket. Back has a center seam and a yoke. There is a vent in the canter back seam. There is a half-belt (consists of two parts) at the back with buttons and buttonholes. Center part of the belt features buttons and buttonholes. Half-belt is fixed to side seams. Set-in long sleeves are two-pieced. Turn-down collar comes with a collar stand with a strap and button closure. There are shoulder straps on the shoulder seams.
Garment also comes with a detachable fur collar, that features buttonloops, whilst the garment’s collar features buttons.

Eases added to a pattern, cm:
Bust-line – 19,6;
Hips-line - 12,5 + model’s widening;
Shoulders - 13,3.

Garment Length Measurements, cm
Finished back length along the center back seam, cm: size 38: 73,0-77,2, size 40: 73,1-81,4, size 42: 73,2-81,5, size 44: 73,3-81,6, size 46: 73,4-81,7, size 48: 73,5-81,8, size 50: 73,6-81,9, size 52: 74,5-82,7, size 54: 74,6-82,8, size 56: 74,7-82,9.

Finished sleeve length, cm: size 38: 60,7-64,6, size 40: 61,1-68,6, size 42: 61,5-69,0, size 44: 61,9-69,4, size 46: 62,3-69,8, size 48: 62,7-70,1, size 50: 63,1-70,4, size 52: 63,5-70,7, size 54: 63,9-71,0, size 56: 64,3-71,3.

Fabric suggestion:
Main fabric. We recommend to use for this garment model coat fabrics of average thickness and density, soft, pliable, with or without nap, well steamed fabrics. It can be fabrics from natural, synthetic or blended fibers.

Finishing fabric. For the detachable collar you can use faux fur with average length nap or with long nap.
Lining fabric. As lining you can use fabrics with same properties that main fabric features (pliability and density). It can be fabrics from natural, synthetic or blended fabrics.
Insulation material. To insulate the garment we recommend to use interlining fabric of insulation, Wollwatteline VTL, 70% wool, 30% viscose 160 gr/m2.

Amount of Fabrics (in metres):
Main fabric, wide 140 cm: size 38: 2,00-2,05, size 40: 2,05-2,20, size 42: 2,10-2,25, size 44: 2,15-2,35, size 46: 2,20-2,40, size 48: 2,25-2,45, size 50: 2,30-2,45, size 52: 2,35-2,55, size 54: 2,40-2,60, size 56: 2,45-2,65.
Lining fabric, wide 140 cm: size 38: 1,40-1,50, sizes 40-42: 1,45-1,60, size 44: 1,50-1,65, size 46: 1,55-1,65, size 48: 1,55-1,70, size 50: 1,60-1,75, size 52: 1,65-1,80, sizes 54-56: 1,70-1,85.
Insulation material (150 g/m2; width 140 cm): size 38: 1,50-1,55, sizes 40-42: 1,50-1,65, sizes 44-46: 1,55-1,70, size 48: 1,55-1,75, size 50: 1,60-1,75, size 52: 1,75-1,90, size 54: 1,80-2,00, size 56: 1,90-2,10.
Finishing fabric (faux fur), wide 140 cm: sizes 38-56: 0,30.
The rubber cord, wide 20 mm: size 38-56: 0,15.
Interfacing (density 55 g/m2; width 150 cm): size 38: 1,45-1,55, size 40: 1,45-1,60, size 42: 1,50-1,65, size 44: 1,60-1,70, size 46-50: 1,60-1,75, size 52: 1,65-1,80, size 54: 1,70-1,85, size 56: 1,75-1,90.
Fusible facing straightener with the density of 64 gr/m2 and the width of 90 cm: sizes 38-56: 0,20.
Bias fusible tape with reinforcement stitches: size 38: 2,15, size 40: 2,20-2,25, size 42: 2,20-2,30, size 44: 2,25-2,35, size 46: 2,30-2,35, size 48: 2,35-2,40, size 50: 2,40-2,45, size 52: 2,45-2,50, size 54: 2,50-2,55, size 56: 2,55-2,60.
Fusible on grain tape: size 38: 4,00-4,15, size 40: 4,05-4,30, size 42: 4,10-4,30, size 44: 4,10-4,35, size 46: 4,15-4,35, size 48: 4,20-4,40, size 50: 4,20-4,45, size 52: 4,25-4,45, size 54: 4,25-4,50, size 56: 4,30-4,50.

Attention! Given exact fabric consumption can be used only when pattern details are placed on a fabric sheet close to each other. All pattern details should be arranged on an opened fabric sheet strictly on grain in one direction, each pattern piece must be cut out only once.

Garment accessories:
Buttons with the diameter of 22 mm – 18 pcs.
Buttons with the diameter of 8-10 mm – 5 pcs.
Small button, diameter 10 mm– 10 pcs.
10-12.5 mm diameter snap buttons – 2 pcs.
One pair of the attachable sleeve cap pad with the width of 15 mm.
Sleeve head – 2 pcs.

Pattern is given with seam allowances.

Detailed sewing instruction with step-by-step photos of sewing is attached to the pattern in the kit.

Degree of difficulty - "Advanced”.


The photos shows a coat sewed at the GRASSER  for pattern №970.

Model is wearing a size 42, height 176-182. Model parameters: Bust-line: 92 cm, waist-line: 64 cm, Hips: 97 cm, Height: 179 cm.


The images also shows: turtleneck sweater on pattern №913, skirt on pattern №669, trousers on pattern №969.



For sewing you will need the following equipment:
  • Multipurpose sewing machine;
  • An iron with or without steam;
  • Regular presser foot;
  • Wooden iron;
  • Ironing desk or console table;
  • Hand needle for basting;
  • Machine needles №80-90 for the main fabric;
  • Machine needles №70 for the lining;
  • Paper scissors;
  • Scissors for textile cutting.



The pattern in your order will be in two print options:
1. For printing on A4/Letter. You need to print the pattern on a regular printer on A4/Letter sheets, then glue the sheets, cut the pattern and you can sew!
A test square for checking the A4/Letter print scale is located on the first sheet of the pattern file.

2. For printing on a large format plotter.
A test square for checking the plotter scale is located on the pattern sheet.
